0.6/1kV聚氯乙烯绝缘聚氯乙烯护套电力电缆
0.6/1kV polyvinyl chloride(PVC)insulated and protective covered powercable
（含普通型、阻燃型、耐火型）
（Including conventional,flame-retardant and fire-resistant types)
一、 产品特点及用途 Features and applications
聚氯乙烯绝缘聚氯乙烯护套电力电缆具有良好的电气性和化学稳定性，结果简
单，
使用方便。本产品适用于交流额定电压U0/U为0.6/1kV及以下的输配电电线路上。
阻燃电力电缆的主要特点是电缆不易着火或着火是延燃仅局限在一定范围内，适用于电缆敷设密集程度较高的发电站、地铁、隧道、高层建筑、大型工矿企业、油田、煤矿等场所。
耐火电力电缆的主要特点是电缆除了能在正常的工作条件下传输电力外，电缆在着火燃烧时仍能保持一定时间的正常运行，适用于核电站、地铁、隧道、高层建筑等与防火安全和消防救生有关的地方。
PVC insulated and protective covered power cable,whose electirc property
and chemical stability are excellent,is simple in structure and
convenient in application.This manufactu is applicable to the
transmission and supply line,of which the AC rated voltage Uo/U iS
0.6/1kV or lower level.
The flame-retardant power cable is not easily to catch fire and it can
confine the fire in some limited area,therefore the cable is applicable
to the places where the density of cable laying is high,such as
generating station,subway,tunnel,high-rise building,large industrial and
mining establishment,oil field,coal mine and so on.
The fire-resistant power cable is ,beside the power transmission under
normal condition,can continue operating normally for some time when it
catches fire,so it is applicable to the places which is concerned to the
fire protection such as nuke,subway,tunnel,high-rise building and so
on.
二、产品标准 Standards
本产品按GB/T 12706.1-2008或IEC 60502标准组织生产，还可按用户要求的其它标准生产。
阻燃型电缆除按上述标准外，其阻燃性能按GB/T 18380.3-2008或IEC 60332-3标准规定分成A、B、C、D四种不同的阻燃类别，A级类别的阻燃性能优，用户可根据需要选用。
耐火型电缆的耐火性能按GB／T 19216.21-2003生产。
This manufacture is produced according to the standard GB/T 12706.1-2008
0r IEC 60502,and we can also manufacture it to meet your needs.
The flame-retardant power cable,besides the foregoing standard,its fire
retardant is divided in to4 types,A,B, C and D,according to the standard
GB/T 18380.3-2008 0r IEC 60332-3,of which A performances best.You can
adopt anyone to meet you need.
The fire performance of the fire-resistant power cable is according to the standard GB/T 19216.21-2003.
三 、产品型号 Types of products
◆普通型电缆型号 * Conventional type
VV-铜芯聚氯乙烯绝缘聚氯乙烯护套电力电缆 VV -copper core,PVC insulated and protective covered power cable
VV22-铜芯聚氯乙烯绝缘钢带铠装聚氯乙烯护套电力电缆 VV22 -copper core,armored,PVC insulated and protective covered power cable
◆阻燃型电缆型号 * Flame-retardant type
在普通型号电力电缆型号前加Z (A．B．C．D) Add Z(A.B.C.D)before the conventional types
◆耐火型电缆型号 * Fire-resistant types type
在普通型电力电缆型号前加N Add N before the conventional types
四、产品使用特性 0perating characteristics
（1）额定电压U0/-U为0,6/lkV。 rated voltage Uo/U is 0.6/lkV
（2）电缆导体的高额定温度为70℃。 maximum rated temperature of conductor is 70℃
（3）短路时（长持续时间不超过5S）电缆导体的高温度不超过160℃。maximum temperature when in short circuit(no Ionger than 5s) is 160℃
（4）电缆敷设时的环境温度应不低于0℃，其小弯曲半径如下：minimum surrounding temperature of cable laying is OoC,minimum bend radius is
单芯电缆-20I(D+d)，mm singlecore cable-20(D+d),mm
多芯电缆-15(D+d)，mm multicore cable-15(D+d),mm
（D、d分别为电缆外径与主导体的标称直径，mm）（D and d are the external diameter ofcable and the nominal diameter ofconductor)
五、主要技术参数 Technical parameters
电缆载流量计算条件 The condition of current carrying capacity account
环境温度25℃ Surrounding temperatureis 25℃
电缆导体工作温度70℃ Operating temperature of conductor is 70℃
电缆埋地敷设时，土壤热阻系数g=1C.m/W,但尚未考虑电缆长期运行时由于水分迁移而导致土壤热阻系数升高 的现象。Soil thermal
resistivity when Iaying the cable is g=l.0C.m/W (the rise of soil
thermal resisitivtiy attribute to water migration when long operating is
not taken into account.)
电缆埋地敷设时，电缆的轴心与地面距离为1000mm。The distance between cable axes and the ground when laying the cable is lOOOm
多跟电缆敷设时，电缆的轴心距离S=3D The distance between two cable axes is S=3D
VV Z(A.B.C.D)-VV N-VV 0.6/1
|
标称截面
Nominal
section
mm2
|
电缆参考外径
Cable referenced
Outer diameter
mm
|
允许载流量A
Allowable ampacity
|
电缆参考重量
Cable referred
weightkg/km
|
|
空气中敷设
air laying
|
埋地敷设
ground laying
|
|
|
Cu
|
Cu
|
Cu
|
|
1.5
2.5
4
6
10
16
25
35
40
70
92
120
150
185
240
300
400
500
630
|
6.8
7.2
8.1
8.6
10.0
11
12.7
13.9
15.6
17.4
19.7
21.4
23.3
25.6
28.7
31.7
35.1
38.6
42.3
|
24
32
42
54
75
99
132
162
194
246
298
346
395
457
550
636
745
846
1043
|
33
44
57
73
101
133
175
210
250
314
375
430
484
549
640
726
834
959
1113
|
61
74
100
124
183
241
367
475
618
840
1134
1384
1683
2084
2696
3355
4246
5092
6362
|
|
2×1.5
2×2.5
2×4
2×6
2×10
2×16
2×25
2×35
2×50
2×70
2×95
2×120
2×150
2×185
|
10.5
11.3
13.1
14.1
16.7
18.8
22.3
24.6
23.1
25.7
29.3
31.7
35.0
38.6
|
19
26
35
44
60
80
107
131
152
194
238
275
318
366
|
25
34
33
56
76
100
129
157
187
233
278
318
357
404
|
129
158
221
274
378
519
758
978
1217
1613
2157
2658
3296
4027
|
续表
|
标称截面
Nominal
section
mm2
|
电缆参考外径
Cable referenced
Outer diameter
mm
|
允许载流量A
Allowable ampacity
|
电缆参考重量
Cable referred
weightkg/km
|
|
空气中敷设
air laying
|
埋地敷设
ground laying
|
|
|
Cu
|
Cu
|
Cu
|
|
3×1.5
3×2.5
3×4
3×6
3×10
3×16
3×25
3×35
3×50
3×70
3×95
3×120
3×150
3×185
3×240
3×300
3×400
|
11.0
11.9
13.8
14.9
17.6
19.9
23.7
26.1
26.4
29.8
33.8
36.7
40.2
45.6
51.7
56.1
74.8
|
17
22
29
37
52
68
91
112
133
171
209
242
282
329
392
450
529
|
22
29
38
47
65
85
110
134
159
199
237
271
305
340
400
454
519
|
154
194
274
348
529
740
1058
1382
1760
